All Products

Model No.: USI-908A

Fowler Bed 2 Function Manual

Description

  •  Four Section perforated platform.
  • Platform size: : 2000L x 900W mm
  • Platform is provided with side supports to immobilize the mattress upon the platform.
  • Bumpers at four corners of the bed are provided.
  • ABS/Blow Moulded Head and Foot Panels
  • ABS/SS/MS foldable side Railings.
  • Functions: Two function i.e. Back Rest and Knee Rest.
  • Backrest, Knee-Rest through two screw system with thrust bearing individually manoeuvred by two handles.
  • Backrest, Leg section and Foot section can also be adjusted manually.
  • Four Swivel castors of dia. 100mm with diagonal locking are provided.
  • Load Bearing Capacity of 180 kg.
  • Provision for IV Rod provided at four corners of the bed.
  • Pre-treated and powder coated tubular M.S. steel frame.
  • Mattress with appropriate size to incorporate with the bed.
  • Four Section Mattress of approx. 5 inches thick and 40 kg/m³ Density and Rexene cover which is anti-static, flame retardant, disinfectant and liquid proof.
  • Optional Accessories:
    • Set of tools required for assembly of the Fowler Bed.

Model No.: USI-AT019

ABS Base for OT Tables

Description:

For Model No. USI – 2005 Plus, 2005 pro, 2005, 2009,

Model No.: USI-AT012

Accessories Trolley

Model No.: USI - E8

STRETCHER TROLLEY (HYDRAULIC)

Description:

  1. Foot operated Hydraulic System mechanism by stepping on the pedal located on both sides of stretcher for Hi – Low, Trendelenburg & Reverse Trendelenburg adjustments.
  2. Smooth Pneumatic mechanism to raise Backrest.
  3. Kneerest position Obtained by Smooth Crank System with S.S. Foldable Handle at foot end.
  4. Four section X-Ray permeable Platform Top along with Suitable Mattress of 100 mm (4”).
  5. Two Pieces Individual Detachable Collapsible Safety Side-Rails with safety lock, Stainless Steel Pipe
  6. Provided with Push/Driving Handle on the head end for smoothing the way of movement conveniently and can be stored while not in use.
  7. Tubular M.S. Framework mounted on 200 mm (8”) Central Locking Castors
  8. Bottom Cover with Storage bin.
  9. Corner buffer provided at 4 locations.
  10. Urine bag holder provided at both sides.
  11. S.S. Telescopic I.V. Rod with 4 Hook’s (USI-5002) & provision on all 4 sides

Dimensions (Approx.) :

  1. Overall Size: 2040L x 810W x 600 – 920H mm
  2. Stretcher Top Size: 1930L x 735W
  3. Angle of Back Section: 90°
  4. Angle of Leg Section: 25°
  5.  Angle of Trendelenburg / Reverse Trendelenburg: 12°/ 10°

Optional Accessories:

  1. Fifth Wheel
  2. Oxygen Cylinder Holder
  3. Foot end Shelf



Model No.: USI - 1069 PLUS

EMERGENCY & RECOVERY STRETCHER TROLLEY (HYDRAULIC)

Description:

  1. Heavy duty non- staining precision ball bearing swivel casters of 8” for easy maneuverability.
  2. Casters- Foot operated and centrally actuated lever at head/foot ends with multistage switching for total lock, direction look or free mobility
  3. Gas spring assisted seamless adjustment of Trendelenburg and reverse Trendelenburg positions.
  4. Backrest Operated manually on ratchet system.
  5. Convenient height adjustments on high quality hydraulic pump with foot operated levers on both sides of the trolley.
  6. Two section mattress platform made of X-Ray permeable pre-laminated board, supported on strong M.S. Tubular frame with removable stretcher.
  7. Provided with Oxygen Cylinder Cage, Sliding X-ray Cassette holder, Collapsible safety side railings, SS telescopic I.V. Rod with 4 hooks, Utility Tray and Suitable Mattress of 50 mm (2”).
  8. Finish: Pretreated and Epoxy powder coated.

Dimensions (Approx.):

  • Overall Size: 2030L x 1020W x 600-880H mm.
  • Stretcher top Size: 1930L x 660W mm
  • Angle of Back Section: 80°
  • Angle of Trendelenburg / Reverse Trendelenburg: 17° / 15°

Optional Accessories:

  • Fifth Wheel
  • Foot end Shelf

Model No.: USI - 1069

EMEMERGENCY & RECOVERY TROLLEY (HYDRAULIC)

Description:

  1. Tubular M.S. Framework, foot operated hydraulic pump for height adjustment
  2. Smooth Pneumatic mechanism to obtain Trendelenburg and Reverse Trendelenburg positions.
  3. Removable two section X-Ray permeable top with Head Raise on Ratchet Mechanism.
  4. Trolley Mounted on 125 mm (5”) diagonal locking castors
  5. Provided with Oxygen Cylinder Cage, Sliding X-ray Cassette holder, SS drop down safety side railings, SS telescopic I.V. Rod with 4 hooks, Utility Tray and Suitable Mattress of 50 mm (2”).
  6. Finish: Pretreated and Epoxy powder coated.

Dimensions (Approx.):

  1. Overall Size: 2100L x 670W x 690 – 950H mm.
  2. Stretcher top Size: 1940L x 605W mm
  3. Angle of Back Section: 70°
  4. Angle of Trendelenburg / Reverse Trendelenburg: 9°/ 15°

Model No.: USI - 1069A

EMERGENCY & RECOVERY TROLLEY (MANUAL)

Description:

  1. Tubular M.S. Framework
  2. Positions Obtained by Separate Smooth Crank System with S.S. Foldable Handle: Hi – Low & Trendelenburg / Reverse Trendelenburg.
  3. Removable two section X-Ray permeable top with Head Raise on ratchet mechanism.
  4. Trolley Mounted on 125 mm (5”) diagonal locking castors
  5. Provided with Oxygen Cylinder Cage, SS drop down Safety Side Railings, SS telescopic I.V. Rod with 4 Hooks, Utility Tray and Suitable Mattress of 50 mm (2”).
  6. Finish: Pretreated and Epoxy powder coated.

Dimensions (Approx.):

  1. Overall Size: 2220L x 700W x 600 – 810H mm
  2. Stretcher top Size: 1950L x 610W mm
  3. Backrest Angle: 75°
  4. Trendelenburg / Reverse Trendelenburg: 5°/ 9°

Model No.: USI - E3

STRETCHER Luxurious

Description:

  1. Smooth Pneumatic mechanism to raise Backrest.
  2. Hi – Low position obtained by Smooth Crank System with S.S. Foldable Handle at foot end.
  3. Framework made of mild steel mounted on 125mm (5”) Central Locking Castors
  4. Two Section PP Platform Top.
  5. PE engineering plastic moulded two Pieces individual Side Rails.
  6. Bottom Trolley fully M.S. covered
  7. Finish: Pretreated & Epoxy Powder Coated.
  8. Overall Size: 1920L x 680W x 530 – 820H mm.

Model No.: USI - E4

STRETCHER CONNECTING (Luxurious)

Description:

  1. High quality Aluminum material as the main structure, one time automatically pressed
  2. Stretcher can be lift up/down easily with crank, to let the two single stretcher come to the same level and slide the top easily.
  3. It can be locked automatically when the Top slide to single stretcher.
  4. Smooth Pneumatic mechanism to raise Backrest for top.
  5. Hi – Low position obtained by Smooth Crank System with S.S. Foldable Handle at foot end.
  6. Framework made of mild steel mounted on 125mm (5”) Central Locking Castors
  7. Two Section PP Platform Top.
  8. PE engineering plastic moulded two Pieces individual Side Rails.
  9. Bottom Trolley fully M.S. covered
  10. Finish: Pretreated & Epoxy Powder Coated.
  11. Overall Size: 3650L x 640W x 640 – 970H mm.

Model No.: USI - 962

STRETCHER TROLLEY 2 section

Description:

  1. Framework made of Tubular M.S. Pipe with S.S. handle.
  2. 2 Section Platform Top with Fixed 50mm (2”) Mattress.
  3. Trolley mount on 150 mm diagonal Locking castors.
  4. Swing Away Type Safety Side Railing in M.S.
  5. Provided with Adjustable S.S. I.V. Rod, Utility Tray, and Cylinder Cage.
  6. Finish: Pretreated and Epoxy powder coated.
  7. Stretcher Top Size (Handle to handle) : 2090L x 560W
  8. Overall Size: 2090L x 590W x 840H mm.

Model No.: USI - 1016

STRETCHER ON TROLLEY

Description:

  1. Removable Stretcher top on CRCA, ERW tubular Steel trolley mounted on 150mm (6”) Diagonal Locking Castors.
  2. Framework made of 1.25” x 16G vertical and 1” x 18G horizontal CRC tubes.
  3. Suitable Mattress of 50 mm (2”), with Safety Belts.
  4. Finish: Pretreated and Epoxy powder coated.
  5. Stretcher Top Size (Handle to handle) : 2050L x 565W mm.
  6. Trolley Size: 1113L x 580W x 800H mm.

Optional Accessories:

  1. S.S. Telescopic I.V. Rod with 4 Hook’s (USI-5002)
  2. Safety Side-Rails, Swing Away

Model No.: USI - 1008

AMBULANCE STRETCHER

Model No.: USI - 985

AMBULANCE STRETCHER CUM WHEELCHAIR

Model No.: USI - 939

EMERGENCY TROLLEY (ABS)

Description:

  1. Framework made of ABS plastic body with aluminum columns.
  2. Provided with IV Pole, Dust bin (2pcs), Utility Container, File Holder, Defibrillator Shelf, Power outlet at rear with hook, oxygen tank at rear, CPR board at rear & S.S. rail on top.
  3. Trolley having Sliding Side Shelf for writing purpose.
  4. Centralized locking system for 2 small & 3 big drawer.
  5. Provided with adjustable inner partitions.
  6. 125 mm (5”) Diagonal locking castors.
  7. Overall Size (approx.): 850L x 520Wx 950H mm

Model No.: USI - 938

ANESTHESIA TROLLEY (ABS)

Description:

  1. Framework made of ABS plastic body with aluminum columns.
  2. Provided with Dust bin (2pcs), Utility Container, File Holder & S.S. rail on top.
  3. Trolley having multi-bin containers on top for medicines.
  4. Trolley having Sliding Side Shelf for writing purpose.
  5. Centralized locking system for 2 small & 3 big drawer.
  6. Provided with adjustable inner partitions.
  7. 125 mm (5”) Diagonal locking castors.
  8. Overall Size (approx.): 850L x 520Wx 950H mm

Model No.: USI - 938 Plus

MULTI-PURPOSE CRASH CART

Description:

  1. Framework Made up of M.S CRCA sheet
  2. Trolley mounted on 125mm (5”) Twin wheel diagonal locking castors with buffer.
  3. Provided with adjustable Stainless steel IV Pole with 2 hooks (01 pcs) and accessories hanger (01 pcs) .
  4. Stainless steel Top (2 pcs) with raised edges from 3 sides.
  5. Centralised locking system for 2 Small (90 mm H) and 2 Medium (130 mm H) and 1 Large (240 mm H) Drawers.
  6. Multi bins are provided for top drawer.
  7. Accessories Included:  Dust bin on side (2 pcs), File holder on other side (01 pcs), Multi bin tilt-able containers on top (10 pcs), Stainless steel push handles on both sides
  8. Tray Size: 705 x 480 mm & 705 x 225 mm (Top shelve).
  9. Overall Size (Approx.): 1015 W x 565 D x 1650 H mm.



Model No.: USI - 987

SCOOP STRETCHER

Model No.: USI-AT03

Arthroscopy Positing Device

Model No.: USI - 987M

SCOOP STRETCHER (MRI Compatible)

Model No.: USI-1064

Attendant Bed

Description:

  1. Framework made of Rectangular / Square M.S. Tube.
  2. 50 mm (2”) Foam Padded Fixed Mattress Covered with Good Quality Rexine.
  3. Legs fitted with PVC stumps / Shoes.
  4. Finish: Pretreated & Epoxy Powder Coated.
  5. Overall Size: 1840L x 600W x 500H MM

Model No.: USI - 988

SPINE BOARD

Model No.: USI-1010

Attendant Bed cum Chair (STD.)

Description:

  1. Framework made of M.S. Tube.
  2. Fabric is pressed with artificial Leather.
  3. Legs fitted with PVC stumps / Shoes.
  4. Pull-out Design for easy Transforming Chair into bed
  5. Finish: Pretreated & Epoxy Powder Coated.
  6. Overall Bed position: 1870L x 630W x 400H MM.

Model No.: USI - 989

HEAD IMMOBILIZER

Model No.: USI - 1073

AUTOCLAVE (Portable)

Description:

  1. Seamless Construction made up of aluminum alloy with turning lid highly polished.
  2. It comes with one stop cock (Continues bleeding Valve), Safety valve and pressure gauge

Available Sizes:

  1. USI – 1073A : 12”x12” (WxL), 21 Ltrs.
  2. USI – 1073B : 12”x14” (WxL), 24 Ltrs.
  3. USI – 1073C : 12”x22” (WxL), 39Ltrs.

Model No.: USI - 2550

AUTOCLAVE HIGH PRESSURE (Horizontal)

Description:

  1. Shell Consists of Chamber and jacket.
  2. The Chamber is made of thick stainless steel sheet.
  3. To minimize the heat loss the shell has been insulated with glass wool and covered with SS 304G cover.
  4. The Sheet is mounted on a sturdy MS Tubular Stand.
  5. Boiler is fitted with auto pressure control device to set and maintain the chamber pressure.
  6. Door and ring is made of thick stainless steel plate.
  7. Fitted with Semi-Automatic temperature control system, steam lock mechanism & jointless silicon gasket.
  8. Standard Accessories: Water Inlet/Outlet valve, water level indicator with safety valve fitted with boiler, pressure gauge, three-way valve for controlling of sterilizing cycle, auto pressure control system, semi- automatic temp. controller, steam trap wall, low water cut off system with alarm

Available Sizes:

  1. USI – 2550A : 16”x24” (WxL), 6 KW Load
  2. USI – 2550B : 18”x36” (WxL), 8KW Load
  3. USI – 2550C : 20”x48” (WxL), 12KW Load



Model No.: USI - 2551

AUTOCLAVE HIGH PRESSURE (Vertical)

Description:

  1. High Pressure water steam electrically heated vertical sterilizer used for sterilizer of surgical instruments, dressing materials, linen, rubber, plastic material.
  2. Injection liquids by means of steam under pressure of 15 to 20 PSI (adjustable)
  3. Triple Chamber with inner chamber and steam jacket made of thick stainless teel.
  4. All sterilizer is hydraulically tested up to 2.5 times of working pressure.
  5. Outer chamber made of stainless steel reinforced with M.S. Sheet.
  6. Lid is made of thick stainless teel plate single pieces and closed by wing nuts arrangements.
  7. Joint less neoprene gasket does not allow any leakages.
  8. Fitted with Double safety valve, Water level indicator, water inlet and drain valves.
  9. Works on 220V, Single phase, 50Hz, AC Supply.
  10. Comes along with automatic low water cutoff device, digital timer and Temperature control.

Available Sizes:

  1. USI – 2551A : 12”x20” (300×500 mm) (WxL), 2 Nos. Element, 2KW Load, 4Kw Total Load
  2. USI – 2551B : 16”x24” (400×600 mm) (WxL), 2 Nos. Element, 3KW Load, 6Kw Total Load

Model No.: USI - E7

LDR BED (Electric)

Description:

  1. Advance Liner actuator system with IP54 Liquid splash protection (03 pcs. Motor, 01 pcs. Control box, 01 pcs. Handset]
  2. PP Head Panels with metal inserts along with lock and corner buffer.
  3. PP Moulded Two Pieces individual Side Rails.
  4. Tubular framework mounted on 125mm (5”) Central locking castors.
  5. Three-section top made of Bakelite sheet covered with 3 section Removable suitable Mattress.
  6. Positions Obtained/Function’s by Patient Hand Remote: Backrest, Hi – Low, Trendelenburg & Reverse Trendelenburg.
  7. Leg end section can slide under the main section.
  8. Height adjustable a pair of foam padded knee crutches.
  9. S.S Telescopic I.V. Rod with 4 hooks
  10. Detachable S.S. Tray
  11. Provided with adjustable S.S. Grip Handles on both sides.
  12. Finish: Pretreated and epoxy powder coated.

Dimensions (Approx.):

  • Overall Size: 2000L x 950W mm
  • Platform Size (full extended): 1900L x 660W
  • Platform Size (Leg section Slide under):1360L x 660W
  • Minimum Height (without Mattress): 680mm
  • Maximum Height (without Mattress): 960mm
  • Backrest angle: 60°
  •  TB / RTB: 9° / 12°



Model No.: USI - H7

LDR BED (Hydraulic)

Description:

  1. Foot operated Hydraulic System mechanism by stepping on the pedal located on either side of the table for Hi – Low adjustment.
  2. Backrest, Trendelenburg & Reverse Trendelenburg position Obtained by Smooth Crank System with S.S. Foldable Handle behind head end.
  3. Heavy PP Head Panel with metal inserts along with lock and corner buffer.
  4. PP Moulded two Pieces individual Side Rails.
  5. Tubular framework mounted on 125mm (5”) Central locking castors.
  6. Three-section top made of Bakelite sheet covered with Removable suitable Mattress.
  7. Leg end section can slide under the main section.
  8. Height adjustable a pair of foam padded knee crutches.
  9. S.S Telescopic I.V. Rod with 4 hooks
  10. Detachable S.S. Tray
  11. Provided with adjustable S.S. Grip Handles on both sides.
  12. Finish: Pretreated and epoxy powder coated.



Dimensions (Approx.):

  •     Overall Size: 2000L x 950W mm
  •     Platform Size (full extended): 1900L x 660W
  •     Platform Size (Leg section Slide under): 360L x 660W
  •     Minimum Height (without Mattress): 670mm
  •     Maximum Height (without Mattress): 920mm
  •     Backrest angle: 50°

Model No.: USI - 1091

OBSTETRIC LABOUR TABLE (Adjustable Height)

Description:

  1. Foot operated Hydraulic System mechanism by stepping on the pedal located on either side of the table for Hi – Low adjustment.
  2. Backrest, Trendelenburg & Reverse Trendelenburg position Obtained by Smooth Crank System with S.S. Foldable Handle behind head end.
  3. Stainless steel Swing away type Head Panel along with safety side Rails.
  4. Tubular framework mounted on 125mm (5”) Castors(all with Lock).
  5. Three-section top made of Bakelite sheet covered with Removable suitable Mattress.
  6. Leg end section can slide under the main section.
  7. Height adjustable a pair of foam padded knee crutches.
  8. S Telescopic I.V. Rod with 4 hooks
  9. Detachable S.S. Tray
  10. Provided with adjustable S.S. Grip Handles on both sides.
  11. Finish: Pretreated and epoxy powder coated.

Dimensions:

  1. Overall Size: 1900L x 900W mm
  2. Platform Size (full extended): 1800L x 660W mm
  3. Platform Size (Leg section Slide under): 1260L x 660W mm
  4. Minimum Height (without Mattress): 670 mm
  5. Maximum Height (without Mattress): 920 mm
  6. Backrest angle: 50°
  7. TB / RTB: 9° / 12°





USI – 1091B : – Also Available in Stainless Steel Frame



Model No.: USI - 1090

OBSTETRIC LABOUR TABLE (Fixed Height)

Description:

  1. Backrest, Trendelenburg & Reverse Trendelenburg position Obtained by Smooth Crank System with S.S. Foldable Handle behind head end.
  2. Stainless steel Swing away type Head Panel along with safety side Rails.
  3. Stainless steel Tubular framework mounted on PVC stumps/shoes.
  4. Three-section top made of Bakelite sheet covered with Removable suitable Mattress.
  5. Leg end section can slide under the main section.
  6. Height adjustable a pair of foam padded knee crutches.
  7. S Telescopic I.V. Rod with 4 hooks.
  8. Detachable S.S. Tray
  9. Provided with adjustable S.S. Grip Handles on both sides.
  10. Finish: Stainless steel.

Dimensions:

  • Overall Size: 1900L x 900W x 760H  mm
  • Platform Size (full extended): 1800L x 660W mm
  • Platform Size (Leg section Slide under): 1260L x 660W mm
  • Backrest angle: 50°
  • TB / RTB: 9° / 12°



USI – 1090A : – Also Available in M.S. Pretreated & Epoxy powder coated Frame
